Special Function Registers (SFR) - These are named registers in memory banks 0 and 1
Interrupt Controller: INTCON
Status Flags: STATUS
Program counter: PCL
I/O Ports: PORTA and PORTB
Data direction: TRISA and TRISB
General Purpose Registers - without names
In memory bank 0 these are at address from 0x20 to 0x7F.
In memory bank 1 these are at address from 0xA0 to 0xFF.
The 16 registers from 0x70 to 0x7F are duplicated in both memory banks.
Read Only Memory
Non Volatile - retains its data when the power is off.
Can never be erased so it's useful for chip "firmware",
the code that allows the chip to be programmed.
Random Access Memory
Volatile - data is lost when the power is off.
It's used to store temporary data like measurements from sensors.
Non volatile memory
It can be erased and re-programmed
It's useful for the code and data tables uploaded into the chip by the programmer.
